METTLER TOLEDO
Industrial Catalog 2015
www.mt.com/ICS9-scales
Platforms for the ICS689
3
Service
5
Interfaces, Plugs, Adapters
RS232, RS422, RS485, Ethernet, USB Device, USB Host, digital I/O, WLAN
I/O Accessories
Relay box for digital I/O incl. power supply
Mechanical Parts
Protective cover for terminals
Wall bracket
Desk mounting plate
Stands
In many heights and versions
Others
Printers, interfaces, cables and much more
Accessories / Communication
4
Installation & Setup
Installation, setup, data loading, user training to ensure fast, initial start-up
Qualification
Equipment qualification to meet your local or international quality system requirements
Calibration
Calibration and certification to meet production or regulatory requirements
Preventative Maintenance
On-going maintenance to ensure dependable operation and long equipment life
Industrial Compact Systems
Resolution e1/e2
2x 3,000e MR*
Capacity & Readability*
3 kg 6 kg 15 kg 30 kg 60 kg 150 kg 300 kg
600 kg
Platform Size (mm)
A 240 × 300**
1 g 1 / 2 g 2 / 5 g
BB 300 × 400**
5 / 10 g 10 / 20 g
B 400 × 500
5 / 10 g 10 / 20 g 20 / 50 g
BC 500 × 650
10 / 20 g 20 / 50 g 50 / 100 g
CC 600 × 800
10 / 20 g 20 / 50 g 50 / 100 g 100 / 200 g
QA 229 × 229
1 / 2 g
QB 305 × 305**
2 / 5 g 5 / 10 g 10 / 20 g
QC 457 × 457
10 / 20 g 20 / 50 g
* Approved by Weights & Measures: OIML Class III 2x 3,000e (1x3000e for 3kg platform), NTEP 5,000d, Resolutions up to 30,000d, not approved by W&M.
** …C-types with welded columns available
