METTLER TOLEDO
Industrial Catalog 2015
Scales
Simple But Efficient
The cost effective scales for many applications
in dry and occasionally wet industrial environments.
3 –150 kg
BBA236
For Demanding
Applications
The BBA236 stainless-steel scale is a robust
and easy to operate all-in-one solution and
a perfect fit for many applications in dry and
short time wet industrial environments. The
user-friendly terminal, with its highly visible
display, is fast and easy to operate and mea-
surably improves production efficiency.
15’000 d (OIML Class III, 3,000e)
6.6 lbs to 330 lbs (3 kg to 150 kg)
Stainless steel (1.4301 / AISI304)
3 sizes from 240 x 300
to 400 × 500
7-digit, 7-segment 60 mm/2.36",
LCD display with white backlight
7 membrane keys
Stainless steel (1.4301 / AISI304)
IP65
RS232
85–264 VAC, 50/60 Hz
NiMH rechargeable battery (option)
Weighing, Checkweighing, Counting,
Totalizing and Animal weighing
Resolution (approvable)
Capacity
Dimensions (W×D×H)
Display
Keypad
Terminal Housing
Ingress Protection
Interfaces
Power Supply
Applications
