METTLER TOLEDO
Industrial Catalog 2015
www.mt.com/bench-scales
Scale Material
Platform Frame: Electro-polished stainless steel
(1.4301 / AISI304)
Load Plate Material
Brushed stainless steel (1.4301 / AISI304)
Protection
PBA226:
IP65
PBA426(x):
IP65/IP67
PBA429(x):
IP68/IP69k
Scale Interface
Analog
Accessories
Hygienic-Kit
Hazardous Area Approval
PBA426x:
ATEX: Cat2GD / I.S. Class I, II, III,
Division 1
PBA429x:
ATEX: Cat2GD / I.S. Class I, II, III,
Division 1
Suitable Indicators
Safe Area:
IND23_, ICS4_5, IND560,
IND690, IND780, IND890,
ICS4_9, ICS6_9
Hazardous Area:
IND226x, ICS466x, IND560x
3–150 kg
Res. E1
1× 3,000e
Capacity
3 kg
6 kg
15 kg 30 kg 60 kg 150 kg
Platform Size (mm)
A 240×300
1 g
2 g
5 g
BB 300×400
10 g
20 g
B 400×500
10 g
20 g
50 g*
QA 229×229
2 g
QB 305×305
5 g
10 g
20 g
QC 457×457
20 g* 50 g*
Optional
up to 15,000d
* only available for the PBA226 models
PBA226,
PBA426 & PBA429 –
PBA426x & PBA429x
Highest Flexibility
Designed according to hygienic standards,
these stainless steel platform series offer fast
and easy cleaning. Due to the different high
end load cell technologies used in the vari-
ous series, protection degrees from IP65 up
to IP68/IP69k are available.
The PBA226, PBA426(x) and PBA429(x)
stainless steel platform series are robust,
durable and economical. They offer solutions
for a wide range of weighing tasks and
applications.
PBA226 models
feature a specially
designed aluminum load cell for any light-
duty wet application.
PBA426(x) models
feature a potted stain-
less steel load cell built around the latest
strain gage technology with improved resist-
ance against the impact of water & humidity.
PBA429(x) models
feature an advanced
welded, hermetically sealed load cell for any
application in wet and harsh environments.
The PBA429x and PBA426x series are ATEX
& FM approved versions.
