METTLER TOLEDO
Industrial Catalog 2015
Product Inspection
Pallet
Packer
Manual / Pallet
Aggragation
Station
Advanced Bundle Station (ABS)
Transparency in Aggregation
Tracking and Labeling for Compliance
with Aggregation Regulations
The Advanced Bundle Station (ABS) is a
module for the aggregation of bundles within
the Track & Trace process. A high resolution
camera reads the 2D codes of all folded
boxes in a complete bundle – even through
the foil. Codes are verfied, and the allocation
of the folded box to the bundle is recorded
and registered in an internal database. The
bundle is marked with a unique serial num-
ber – either by direct print on the bundle or
through the application of a printed label by
an independent packaging unit.
Shipping Case Station (SCS)
Transparency in Aggregation
Compact Control Unit for the Aggregation
of Shipping Cases
The Shipping Case Station (SCS) is the
module for the aggregation of shipping
cases within the Track & Trace process and
ensures transparency in the pharmaceuti-
cal packaging process. The high-resolution
camera reads the 1D and 2D codes on all
single folding boxes or bundles of a com-
plete shipping case. The allocation of the
folding box or bundle to the shipping case
will be recorded and registered in an external
database. The shipping case is marked with
a unique serial number either by a direct
printing or by the application of a printed la-
bel through an independent packaging unit.
The code reading within the case packer
ensures high process reliability as all pack-
aging units are already placed inside the
shipping case.
Manual Aggregation Station (MAS)
Transparency in Aggregation
Marking and Labeling – for Complete
Traceability
The Track & Trace portfolio is completed by
the Manual Aggregation Station (MAS). The
MAS is designed for manual aggregation of
boxes up to bundles, cartons and pallets and
provides conformance with Track & Trace
labeling. The MAS comprises of a scanner,
printing system and Pilot Line Manager (PLM)
allowing operation to take place at different
positions down the line. The MAS is designed
as stand-alone system to offer an optimum
solution for the individual requirements of
packaging lines. This ensures the maximum
flexibility for the last aggregation step. The
self-contained design ensures the system is
ready for use without delays in production.
Integration into existing lines is made pos-
sible with the PLM.
www.mt.com/pce
