METTLER TOLEDO offers solutions
for weighing on the move. Our
pallet scales are modular in design
and can be configured to meet
different handling and connectivity
requirements. The scale carriage
is constructed of solid steel and
designed to withstand years of
heavy use.
Read more about pallet scales
on page 86
Measurement
Tape 19mm × 3m (10ft)
Units
US - inches (rounded to whole, half or tenth)
Metric - cm (rounded to whole or half), mm
Communications
Bluetooth ® Class 2 SPP and HID profiles
USB Types AB for data transfer and recharge
Power
Li-ion 970mAh with 2-hour recharge cycle
Duty Cycle Minimum 2 days on heavy duty cycle
Display OLED 128 × 128 @ 24 bit full color
Scanner
1D Optical 650nm visible laser diode
Program Common symbologies and features
Functions
Five Buttons Brake/Measure, Scan/Record, Send/Next, Save/Append, Back/Power
Shortcuts Insert Pallet, Same as Last, Append
Ergonomics Tactile, 3 x LEDs, buzzer
Physical
Dimensions 123mm x 72mm x 31mm
Weight Approximately 0.500 lb
Software
SDK .NET and .NET Compact Framework, Desktop, PDA and PDA wedge sample applications
ScanTape Manager Configuration and management utility
PDA Pairing Utility
Windows Mobile and WinCE utility to simplify and streamline connection
and data transfer to qualified Motorola PDAs
Regulatory
Environment C-Tick, CE and FCC Certifications
Metrology NMI 13-1-23, MID pending
Other
Application Programmable/Configurable
Temperature -20°C to 50°C, 14°F to 120°F
Humidity
Operating: non-condensed 10% to 80%
Storage: 5% to 80%
Accessories Tape cassette, Silicone Sleeve, Battery, Rear Cover
Warranty 12 months (excluding tape cassette)
Mobile Solutions
Weigh and Measure on the Move
CSN110 ScanTape™
Mobile dimensioning makes it possible to quickly check dimensions of parcels and pallets at any stage of the
logistics process and can be used by drivers to collect data early, at point of pick-up.
