METTLER TOLEDO
Industrial Catalog 2015
Technical Data and Specifications
Order Number
30092997
Connectivity
Limited only by hardware performance requirements
Supported Devices
Connects to METTLER TOLEDO industrial weighing terminals, as well as labora-
tory scales and non-METTLER TOLEDO products, via the custom configuration
interface
Data Types
Weighing terminal demand print data and standard METTLER TOLEDO industrial
weighing terminal data tables
Data Viewing
Live data transfer monitoring via viewing of multiple devices; detailed view of col-
lected data per device
Data Mapping
Up to 999 per single terminal or cluster. Ability to specify the number of data
fields, length of each field, data type and characters to remove from the incoming
data string, in order to match the desired database format
Search Functionality
Supports search of transaction data by device name and serial number, data
range and data type
Data Reporting
Simple table reports are available to view and print, including entire table or fil-
tered by search parameters. Data can also be exported in .csv format
Diagnostics
Status of live device connection indicated by color-coded icons; diagnostic view
available for troubleshooting device connection
System Requirements
Microsoft
®
Windows 7 or Windows 8 Operating System
Administration
Requires installation of Microsoft SQL Server Express on PC running the Weigh-
Sync application
Licensing
Via USB memory stick dongle. Dongle must remain connected to the PC
running WeighSync. Server installation of WeighSync is not supported
Documentation
User’s Guide included on USB memory stick and accessible via the application
help quick launch button
Trial Period
30-day free trial via application download from
www.mt.com/IND-WeighSyncWeighSync™ DC
Flexible data integration application for weighing terminals
www.mt.com/IND-WeighSync
Data Reporting
Use collected data to create reports
with tables and graphs for use in
MS Excel or other programs or to
use for tracking and tracing.
Industrial Terminal Software
PC Workstation
Ethernet
Network
IND780 Terminals with attached
weighing platforms, scanners and printers
Printer
Label Printer
Barcode
Scanner
