IND780

Industrial Terminal

• Validated precision weighing with

programmable MinWeigh

mini-

mum weight threshold

• Drive-780 vehicle application offers

expanded tables, traffic light/gate

control and the ability to integrate

target control and vehicle weighing

on one platform

Process

•True multi-tasking capability allows

weigh-in or weigh-out sequences

utilizing 2-speed feed, target

and spill values on all 4 scales

simultaneously

• Integrated display of current weight

and rate data for each scale

•Powerful PLC communications

capability including custom

templating of data strings

•Control up to 40 inputs and

56 outputs with internal latching

for feed sequences

The IND780 is part of the new

vanguard of weighing terminal

solutions from METTLER TOLEDO.

Similarity with other members of the

terminal family ensures familiarity of

operation, reducing training and

support costs. Scalability within the

family allows you to select the

solution that is right for you and your

application requirements.

Besides its flexibility, the IND780 is

also offered with a number of focused

solutions. For example, a vehicle

application module allows you to use

the IND780 as the solution for a wide

variety of inbound and outbound

truck weighing applications.

Resolution (approvable)

Dimensions (H×W×D)

Display

Keypad

Housing

Protection

Interfaces

Applications

Special features and

functions

Accessories

Attachable Platforms

Hazardous Area

Approval*

* Please see "Hazardous Area Catalog"

Courtesy Altana

www.mt.com/IND7xx

OIML: Class II, III, IIII to 10000e;

NTEP: Class II 100000d; III, IIIL 10000d

Panel-mount: 220×320×105 mm

Harsh Env. Desk/ Wall: 200×299×235 mm

Backlit, Graphic, LCD, Active TFT Color; 320×240 pixels;

145 mm (5.7in) QVGA

30 tactile feel, membrane keys for numeric entry

of data, control of scale functionality and navigation

Stainless steel

Harsh: IP69k;

Panel:Type

4x/12 (IP65)

Ethernet 10/100-baseT, USB Master, Serial RS232

(Comm 1), Serial RS232/RS422/485 (Comm 2)

Freely programmable, Vehicle, Batching, TaskExpert™

Basic Functionality incl. Step Calibration, CalFree™

Calibration methodlogy; SmartTrac™ Display Modes;

MinWeigh

; TraxDSP™ Digital Filtering, TraxEMT™

Maintenance Diagnostics Suite, InSite

Optional communications interfaces:

PLC (one option only): ControlNet™, Ethernet IP™,

Profibus

DP; PROFINET, DeviceNet™, RIO, Modbus TCP;

Serial (One or two): RS232/422/485 demand

or continuous format; up to 115.2k baud

Optional I/O Interfaces: Local: (2) 4 inputs/4 outputs (Relay);

Pulse Counter Input; 4-20 mA Analog Output; Solid state relay;

Remote: (8) ARM100 I/O modules, 4 in/6 out

4: analog, POWERCELL

, IDNet, WM/WMS/WMH

or X-bases, Sum

ATEX: Cat 3GD

UL:

Class I, II, III ; Div 2; Groups C,D

IECEx: Ex nA nL [nL] IIB T4
