Industrial Terminals
Manage recipes, orders, batch history, printing and
track-and-trace requirements with the BatchTool 780
PC tool. Multiple batch terminals can be networked
to a single PC, via Ethernet TCP/IP. Create, edit and
refine recipes. Create production orders and download
them to the IND780batch terminal, where the operator
can view an Order List and make a selection to initiate
production.
BatchTool 780
PC-based Utility
Scales and Flow Meters
Up to 4, operated and displayed simultaneously
Master recipe
Up to 1,000 stored recipes, each containing up to 99 steps
Batch size adjustment
Batch size adjustment per order by %, target value or ingredient amount
Power loss recovery
After a loss of power during processing, system recovers to Pause mode without loss of data, permitting completion of batch
Configuration and setup
BatchTool 780 PC-based configuration tool provides the interface to manage equipment, materials, recipes, orders, and reports
Material management
Up to 999 material paths are supported (maximum 42 automatic feeds and 28 automatic discharges per scale)
Interface
Display and keypad
TFT color graphical LCD display with backlight; numeric keypad with decimal and clear keys; tare, zero, print, select scale;
screen navigation and enter keys; five softkeys, four application-specific softkeys
Reporting
Includes master recipe listing, batch control recipe history, order summary, material usage, and audit trail reports
Security
Login security levels prevent unauthorized changes to orders and control recipes
Barcode interface
Supports operator scanning of each material via Serial or USB connection
Track & Trace
Logs Batch ID, date, time, user ID, changes during the batch, success/fail status of
batch; stored data can be exported as .csv
Hazardous area approval
IND780 terminal approved for use in Zone 2/22, Division 2 hazardous areas
Digital I/O options
Discrete I/O: Maximum of 40 inputs, 56 outputs.
Local (Relay or Solid State): One or two modules, each with 4 inputs, external sink 5-30 VDC;
4 outputs @ 30 VAC/VDC, 1 A max.
Remote: Up to 8 ARM100 I/O modules, 4 in/6 out @ 30 VDC/250 VAC, 1 A max.
Packaged Batch option
Available, pre-packaged, ready-configured batch solution with operator I/O, automatic operation, single-scale input
www.mt.com/IND780batch
