METTLER TOLEDO
Industrial Catalog 2015
www.mt.com/over-under-checkweighers
ICS__9 General Specifications
Resolution
300,000d; 7,500e, OIML / 10,000d, NTEP
Dimensions
ICS4_9:
132 x 232 x 115 mm
(H ×W× D)
ICS689:
170 x 260 x 114 mm
Display
ICS4_9:
LCD liquid crystal graphical display with backlighting
ICS689:
Color TFT display 320 x 240 pixels
Keypad
ICS4_9:
Tactile-touch membrane keypad (PET), scratch-resistant material
ICS689:
Piezo keypad scratch-resistant material
Housing
Stainless steel 1.4301, AISI 304
Protection
IP69k
Interfaces
1 RS232 ; Optional RS232, RS422 / 485, USB device / host, Ethernet, WLAN, Digital I/O, digital or anlaog 2
nd
scale
Power
100–240 VAC; optional battery 12 V / 2.5 A
Accessories
Cables; Stand (height 330 mm), Wall bracket, Printers, Cover, Rechargeable battery, Battery charger, Relay box, Power supply with 9.28 VDC
Model specific data
ICS429
ICS439
ICS449
ICS469
ICS689**
Applications
Color TFT display
•
colorWeight
®
•
•
•
Configurable soft keys
•
•
•
Numeric (n) / Alphanumeric (a) keypad
n
n
a
Additional Interface Options
1
1
1
1
3
Attachable platforms
1
1
2
2
4*
* maximum 2 analog platforms ** available per Q2/2015
The ICS__9 terminal series is
manufactured according to the
latest hygienic design guidelines.
Its stainless-steel housing and
IP69k ingress protection makes it a
perfect choice for wet applications
in which frequent cleaning is key.
EHEDG NSF
