METTLER TOLEDO
Industrial Catalog 2015
Resolution (approvable)
Dimensions (H×W×D)
Display
Keypad
Housing
Protection
Interfaces
Applications
Special features and
functions
Accessories
Attachable platforms
Hazardous area
approval
* See "Hazardous Area Catalog" for information on the intrinsically safe IND560x
www.mt.com/IND5xx
IND560
Weighing Terminal
100,000d / (approvable): Analog – 10,000e OIML,
10,000d NTEP; IDNet – 100,000d OIML, NTEP
Panel-Mount: 265×160×91.8 mm;
Desk/Wall/Column-Mount (Harsh): 265×160×170.3 mm
Vacuum florescent, 21 mm weight display,
graphical 128×64 dot, SmartTrac™ display modes
25-key tactile-feel keyboard with numeric keypad
Harsh – Stainless steel; Panel – Stainless steel faceplate,
Aluminum chassis
Harsh: IP69k
Panel: NEMA 4/12 (IP65)
COM1: RS232/RS422/RS485, optional Ethernet TCP/IP with
either 1 extra serial port and USB master OR 2 extra serial ports
Filling, Vehicle, Tank, Dynamic/In-Motion Legacy Communi-
cation Protocols, Freely programmable via TaskExpert™
Basic Functionality incl. Step Calibration, CalFree™
Calibration methodology; SmartTrac™ Display Modes;
MinWeigh
®
; TraxDSP™ Digital Filtering, TraxEMT™
Maintenance Diagnostics, InSite
®
SL
Optional communications interfaces: PLC (one option only):
Allen Bradley
®
Remote I/O, EtherNet / IP™, Profibus
®
DP;
DeviceNet™, Analog Output and Modbus
®
/ TCP;
Optional I/O Interfaces: Local: (1) 4 inputs / 6 outputs,
Max. 12 inputs / 18 outputs. Use remote ARM100 modules,
4 inputs / 6 outputs each.
1: analog, IDNet, and POWERCELL
®
PDX
®
.
ATEX: II 3 G EEx nL [nL] IIB T4
II 3 D T85ºC IP6x
FM: Class I Groups A-D, Div. 2; Class II Groups F, G, Div 2;
Class III, Div 2
Class I Zone 2 Group IIC, T4
Solutions for the
Harshest Environments
To withstand the environments of
the pharmaceutical and chemical
industries, the IND560 is approved
for Type 4/12 (Panel) and IP69k
(harsh) protection categories. The
needs of the food and beverage
industries are also met. The unit’s
304 stainless steel construction
and polished, sanitary finish resist
aggressive cleaning agents, high
pressure and temperature clean-
ing requirements dictated by EHEDG
and NSF guidelines. For outdoor
facilities, such as tank or vehicle
scales that need to guard against
lightening strikes, the IND560 PDX
offers the protection of POWERCELL
technology.
Maintain Uptime and
Ensure System Quality
• TraxEMT™, the Embedded Main-
tenance Technician, sets the
IND560 apart. Monitor and ana-
lyze system performance to enable
action before a failure occurs.
• Advanced calibration options
allow for the most cost effective
operation. Use the automated
5-Point or Step Calibration rou-
tines for the highest accuracy. The
exclusive CalFree™ technology is
available to get up and running
without test weights.
• The
InSite
®
SL
application man-
ages terminal configuration and
data files. This indispensable utility
saves and restores IND560 setup
parameters to and from a PC.
• MinWeigh
®
functionality helps
ensure the weighing of your
critical ingredients is always
within acceptable limits by
displaying a warning when the
weight is below the minimum
weight threshold.
