METTLER TOLEDO
Industrial Catalog 2015
Courtesy Altana
www.mt.com/terminals
IND110
Weight
Transmitter
The IND110 load-cell signal conditioner
provides an economical way to connect an
analog strain-gauge scale or weigh modules
to process-control equipment. The IND110
generates a 4–20 mA process signal that is
typically communicated to a remote analog
input on a PLC or other process control
equipment.
–
74 × 100 × 57 mm
–
–
Plastic
IP20
4–20 mA analog signal
20 to 28V DC, 300 mA max, 8 watts,
Class 2 power supply
Simple weighing; Filling; Formulation
Accessories:
For direct interface to PLC’s and other
control equipment; Machinery;
Integration & Engineering
Single platform, 1–4 analog load cells
–
IND131/IND131xx
Junction Box
Process Weighing Terminal
The IND131 Junction Box complements the
IND131 DIN-mount terminal with a load cell
summing board, mounted in a robust stain-
less steel enclosure providing IP69k protec-
tion. The enclosure’s design is service-friendly
and the integrated mounting brackets simply
secure wall-mounting.
10,000d (6,000e OIML, 10,000d NTEP)
251×261×169 mm
6 mm character height (DIN chassis operator)
4 function keys – flat membrane with domed
polyester overlay (DIN chassis operator
interface, internal)
Stainless steel, wall-mountable
IP69k (IND131), IP65 (IND131xx)
Serial, RS232; optional RS485 with
Modbus RTU protocol
Universal AC power supply or 18-36 VDC,
IND131xx (DC only)
Simple basic and gain or loss-in-weight
applications with 2-speed target control
and limit values for three comparators
Process weighing: Direct PLC connectivity –
Analog output, Allen-Bradley
®
RIO, DeviceNet,
EtherNet/IP, Modbus
®
TCP, Profibus
®
DP,
ControlNet (DC only), InSite
®
SL, SD card (AC.)
Single platform, up to 8 analog load cells
(AC version) or up to 4 analog load cells
(DC version)
IND131xx FM: Class 1, 2, 3; Div 2; Groups A–G
ATEX: II 3 G Ex nA nL [nL] IIC T5; II 3 D Ex tD
A22 IP 65 T 100°C; IECEx: Ex nA nL [nL] IIC
T5; Ex tD A22 IP65 T100°C
IND131/IND131xx
DIN-mount
Process Weighing Terminal
The compact IND131 DIN terminal is ideal for
installation requiring a small footprint without
sacrificing display capability. The terminal
shares the same interface, functionality and
connectivity as the rest of the IND131/331
product line.
10,000d (6,000e OIML, 10,000d NTEP)
68 x 138 x 111 mm
6 mm character height
4 function keys – flat membrane with domed
polyester overlay
DIN-rail mount plastic
IP20, Type 1
Serial, RS232; optional RS485 with
Modbus RTU protocol
Universal AC power supply or 18-36 VDC,
IND131xx (DC only)
Simple basic and gain or loss-in-weight
applications with 2-speed target control
and limit values for three comparators
Process weighing: Direct PLC connectivity –
Analog output, Allen-Bradley
®
RIO, DeviceNet,
EtherNet/IP, Modbus
®
TCP, Profibus
®
DP,
ControlNet (DC only), SD card (Accessory)
Single platform, up to 8 analog load cells
(AC version) or up to 4 analog load cells
(DC version)
IND131xx FM: Class 1, 2, 3; Div 2; Groups A–G
