148

METTLER TOLEDO

Industrial Catalog 2015

Product Inspection

Comprehensive Quality Control

Using Vision Inspection

METTLER TOLEDO CI-Vision provides the best available vision inspection technology to

manufacturers seeking an effective and efficient quality control solution for label contents,

container formation and container integrity. CI-Vision systems are turnkey solutions; each

system features a simple touchscreen interface for all facets of operation and uses cut-

ting-edge inspection tools and techniques to ensure every product on the line meets man-

facturer standards.

Intuitive Software Interface

CI-Vision’s CIVCore

®

software is

standard across all CI-Vision inspec-

tion systems, presenting users with

a touch screen interface designed

for ease of use that is packed with

the best inspection tools available.

Inspections for every product on

the line can be saved into profiles,

which CI-Vision can then pre-load

on the system before it ships to cus-

tomers. When a new product is add-

ed to the production line, operators

are presented with in-depth training

wizards that help create new product

profiles. CIVCore offers multi-level

user access, allowing managers to

keep tight controls over high-level

functions without sacrificing usability

for day-to-day operators.

Product Tracking

Many vision systems do not use

product tracking, relying instead

on timing-based systems to fire

cameras and trigger rejection

mechanisms, but METTLER TOLEDO

CI-Vision’s systems use high-resolu-

tion step encoders to track products

as they move through the system

with incredible accuracy, resulting

in more accurate inspections and

ensuring that only defective products

are removed from the production

line. By tracking the products as

they move through the inspection

process, the system is able to sort

rejected products into different bins

depending on the defect detected.

PC Controlled GigE Cameras

Utilizing high-speed data transfer

technology allows our cameras to

quickly transmit large images to

the inspection software, reducing

the time it takes to analyze images

for product defects and allowing

CI-Vision inspection systems to keep

pace with high speed production

lines. Field maintenance is made

easier by the use of standard parts

and technology which further re-

duces downtime.
