METTLER TOLEDO
Industrial Catalog 2015
Printers
www.mt.com/industrial-printers
8808
Heavy Duty
Multi-Part Form Printer
A powerful printer for multi-part forms and
the best choice for vehicle or industrial
applications. Using a high-speed bidirec-
tional print head, the 8808 printer has the
power to print through thick tickets and
forms. Features like 40/66 column print
width, inverted printing, and emphasized
print mode make it a very versatile printer.
8857
Impact Strip Printer
The 8857 Strip Printer is ideal for producing
a printed record of weighing transactions.
The impact printing will not fade over time
like thermal printing. So whatever the appli-
cation, important results are safe for later
reference. Drop in auto-paper loading and
few moving parts make this a durable and
easy-to-use printer.
APR710
Heavy Duty Thermal Printer
The METTLER TOLEDO APR710 is an ideal solution
when rugged, precise and accurate label printing is
required. With the lowest total cost of ownership in its
class, a compact footprint and multiple connectivity
options, the APR710 packs the power of a high-vol-
ume industrial printer into an easy-to-service modular
design. A wide range of media options, including
direct thermal or thermal transfer, ensure the printer is
ready for the most demanding industrial operation.
Heavy duty dot matrix impact ticket/slip printer
Approx. 2 lines / sec.
Up to 1 original + 4 copies
9 pin bidirectional impact
Line length: 84.5 mm/40 columns or 133 mm/
66 columns; Line spacing: 6 lines/inch
Paper:
min. 80×69 mm,
max. 182×257 mm
Max. 4K
9×9 dot matrix default (expanded fonts
through control codes) / 1.6×3.1 mm
–
185×252×266 mm
100–240 V AC/50–60 Hz
UL, CUL, CE, TUV, FCC Class A
RS232 serial, DB25 female connector
–
Serial impact dot-matrix
4.7 lines / sec. (40 columns),
8.6 (16 columns)
Original + 1 copy
9-pin serial
Line length: 40 columns
Line spacing: 0.30–0.35 mm
Paper: 76 mm
Max. 4K
International character fonts,
size varies by font
–
160×248×138 mm
100–240 V AC, 50-60 Hz; 24 V DC 1.3 A
Varies by font
RS232 25-pin (female) serial
–
Direct thermal or thermal transfer
Up to 254 mm/ sec.
–
8 dots /mm
Max. print width 108
Roll or fan-fold, die-cut or continuous labels
0.06 to 0.25 mm thickness, 19 to 118 mm width
Up to 16 MB DRAM, 8 MB Flash
Resident Fonts: Ten alphanumeric fonts from 0.03”
(0.9 mm) to 0.25” (6 mm) Resident scalable fonts
Barcodes: Code 3 of 9, UPC-A, UPC-E, Interleaved
2 of 5, Code 128, EAN-8, EAN-13, HIBC, Codabar,
Plessey, UPC 2 and 5 digit addendums, Code 93,
Postnet, UCC/EAN Code 128, Telepen, UPS Maxi-
Code, FIM, PDF417, USD-8, Datamatrix, QR Code,
Aztec, TLC 39, Micro PDF417, RSS
262×249×459 mm
90–132 or 180–264 V AC @ 47–63 Hz
UL, CE, FCC
USB, Centronics
®
IEEE 1284 Parallel port, RS232
at 1,200 to 38,400 BPS, 9-pin (female) connector
Peel and present, Internal Rewinder, Cutter,
Internal LAN, Internal Wireless LAN
