Tension Weigh Modules
Tension weigh modules are designed for installation where suspended
mounting is required. The ruggedly designed system tolerates the
many adverse loading and environmental conditions commonly pres-
ent in industrial weighing environments while still providing excellent
accuracy.
www.mt.com/load-cells
www.mt.com/weigh-modules
www.mt.com/APW
Model
SWS310 Tension Mount
Max. Capacity (kg)
50, 100, 250, 500, 1,000, 2,500,
5,000, 7,500, 10,000
Resolution
3,000e
OIML approval
C3 OIML
NTEP approval
II 3,000d, IIIL 10,000d
ATEX
Zone 0/1/2 and Zone 20/21/22
approval
FM/cFM
Class I, II, III Div. 1&2
approval
Material
SWS310 / SLS410: nickel plated steel
SWS310 / SLS510: stainless steel
Protection
IP67
Interfaces
Analog 3 mV/V
Applications
Suspended hoppers; Mechanical lever
scale conversions
Accessories
J-Boxes
Weigh Module Accessories
An extensive range of accessories for weigh modules allow for
correct installation in harmful environmental conditions and increase
lifetime and performance of the system.
Accessory
Application
Thermal Pad
Hot tanks up to 170°C
Thermal Pad
Hot tanks up to 82°C
Damping Pad
Isolate from shock loads and vibration
Dead stand
Protect equipment in installation phase;
For liquid level control indoors.
Dummy load cell
Protect equipment in installation phase;
For liquid level control outdoors.
Spacer plate
Fix piping, no lift load cell exchange
