METTLER TOLEDO

Industrial Catalog 2015

Sensors / Load Cells /Weigh Modules

Models

SLP845, SSH, IL

Max. Capacity (kg) SLP845:

15, 22, 50, 100, 200

SSH:

50, 100, 200, 500, 1000

IL:

150, 250, 500, 1,000, 2,000

Resolution

3,000e

OIML approval

C3 OIML R60, OIML 3,000e

Platform size (mm)

Up to 1,000×1,000

Material

SLP845 / SSH:

Stainless steel;

IL:

Nickel plated steel

Protection

SLP845 / SSH:

IP68, laser welded;

IL:

IP67

Interfaces

Analog 2 mV/V

Applications

Bench scales; Floor scales;

Process weighing in food and pharma

Steel:

Single Point Load Cells

Models

MT1022, MT1041, MT1241, MT1260

Max. Capacity (kg) MT1022:

3,5,7,10,15,20,30

MT1041:

10, 15, 20, 30, 50, 75, 100

MT1241:

30, 50, 100, 150, 200, 250

MT1260:

50, 75, 100, 150, 200, 250,

300, 500, 750

Resolution

3,000e (

MT1241:

3,500e)

OIML approval

C3 OIML R60

NTEP approval

III 5,000d

ATEX approval

Zone 1/2 and 21/22

Platform size (mm) MT1022:

350×350;

MT1041:

400×400

MT1241:

400×400;

MT1260:

600×600

Material

Aluminum, passivated

Protection

IP67, potted

Interfaces

Analog 2 mV/V

Applications

Bench scales; Floor scales;

Process weighing

Aluminum:

Single Point Load Cells

A High Level of Accuracy

www.mt.com/load-cells

METTLER TOLEDO offers a wide range of single point load cells. They are typically

used individually in small to medium-sized Weighing Systems. Steel models are used

when higher degrees of protection are required. The moment insensitive design guar-

antees a high level of accuracy even with eccentric load, providing an easy way of

creating high-precision scales. The key features of the cells are ruggedness, accuracy

and a high level of reliability.
