Weigh module systems using POWERCELL
®
load cells
provide the ultimate in accuracy and reliability. The
predictive diagnostics system monitors each load cell,
alerting you to potential problems before they cause
inaccurate weighing or downtime. The unique network
increases reliability by eliminating failure-prone junc-
tion boxes.
Benefits Over Analog Systems:
• Single load-cell diagnostics for
predictive failure detection
• No junction box for high reliability
and fast installation
• Up to 10,000e OIML accuracy
• Calibration without weights
Mechanical Safety Features:
All safety-related mechanical fixtures
are present. Life protection and 360°
horizontal stops withstand high
wind and seismic forces. They also
protect the weighing cell from over-
load. Integrated drop-down protec-
tion ensures safety even in extreme
cases. Two optional stabilizers fix
the tank and allow for high mixer
torques and short stabilization times.
Model
SWB605 PowerMount, SWC515 PinMount PDX
Max. Capacity (kg/t)
220, 550 kg, 1.1, 2.2, 4.4, 20, 30, 50, 90 t
Resolution
3,000e, 6,000e, 10,000e, 5,000d, 10,000d
OIML approval
C3, C6, C10 OIML
NTEP approval
5,000d, 10,000d
ATEX approval
Zone 2 and 22
Hazardous Assessment EN13463-1
FM approval
Class I, II, III Div.2
Material
Zinc plated, 304 stainless steel, 316 stainless steel
Protection
IP68, IP69k load cell stainless steel, welded
Interface
POWERCELL
®
Application
Superior tank and vessel weighing with diagnostic features
Accessories
Cables, vibration and thermal isolation pads, dead stands,
spacer plates; stabilizers
Diagnostics and Accuracy
POWERCELL Weigh Modules
