METTLER TOLEDO
Industrial Catalog 2015
Sensors / Load Cells /Weigh Modules
For Heavy Loads:
Canister / Ring Load Cells
Whether you are operating a truck, rail, or tank scale, inaccurate
weights can cost you money. By ensuring that every weight is accu-
rate, METTLER TOLEDO canister load cells help prevent lost income
due to incorrect billing, customer complaints, and fines for overload-
ing. Advanced load cells are compensated for external influences
such as temperature changes, nonlinearity, hysteresis, and creep.
Models
RLC, SLC610, 0782, POWERCELL
®
PDX
®
Max. Capacity (t) RLC:
0.25, 0.5, 1, 2.2, 3.5, 10
SLC610:
7.5, 15, 22.5
0782:
20, 30, 50, 100, 200, 300
POWERCELL
®
PDX
®
:
20, 30, 50, 90
Resolution
3,000e–6,000e, 10,000d (depending on
model)
OIML approval
C3 OIML R60
Option C4,C5,C6 OIML R60
(depending on model)
NTEP approval
NTEP IIIL 10,000d
ATEX approval
Zone 1/2 and Zone 21/22
(depending on model)
FM/cFM
Class I, II, III, Div. 1 (depending on model)
approval
RLC: Class I, II, III, Div 1&2
Material
Stainless steel
Protection
IP68, laser welded; POWERCELL
®
PDX
®
and POWERCELL
®
: IP68/ IP69k, glass to metal
Interfaces
Analog 2 mV/V;
POWERCELL
®
: High Performance
Applications
RLC:
Low profile weighing; High precision weighing
SLC610:
Tank weighing
0782:
Vehicle weighing; Tank weighing
POWERCELL
®
PDX
®
:
High performance weighing
Accessories
Load receivers, J-Boxes
From 5 kg – 4.4 t:
Beam Load Cells
METTLER TOLEDO beam load cells are available from 5 kg–4.4 t.
This type of construction provides an ideal combination of
compact design and high weighing precision. To withstand the
harsh industrial environment, models are available in a
stainless-steel and fully welded version. This guarantees a high level
of reliability and operational safety. All listed beam load cells have
the major approvals OIML, NTEP and Ex certification ATEX, FM as
standard, considerably simplifying your logistics.
Models
MTB, 0745A, SLB215, SLB415
Max. Capacity (kg) MTB:
5, 10, 20, 50, 100, 200, 300, 500
0745A / SLB215 / SLB415:
110, 220, 550,
1,100, 2,200, 4,400
Resolution
3,000e, 6,000e
OIML approval
C3, C6 OIML R60
NTEP approval
NTEP 3,000d, 5,000d, 10,000d
ATEX approval
Zone 1/2 and Zone 2/22
FM/cFM
Class I, II, III, Div. 1&2
approval
Material
Stainless steel, nickel plated steel
Protection
IP67, IP68 laser welded
Interfaces
Analog 2 mV/V
Applications
MTB:
Low capacity tank weighing,
process control
0745A:
Floor scales, tank weighing,
process control
SLB215 / SLB415:
Packaging, dry filling,
warehouses
Accessories
J-Boxes, Load cell accessories
