METTLER TOLEDO
Industrial Catalog 2015
Model
AJB540S, AJB541M, AJB540L, AJB641S,
AJB841S, AJB641SX, AJB841SX
No of load cells
4
ATEX approval
Zone 1/2 and 21/22
Material
304 stainless steel, 316 stainless steel
Protection
IP65, IP69k
Application
Multi load cell system
Analog Junction Boxes:
For Weigh Modules and Load Cells
The METTLER TOLEDO analog junction boxes are suitable for quick
and simple connection of multiple load cells to weighing electronics.
S-Type Load Cells
S-Type load cells are typically used to convert supended hoppers
or other hanging devices into a weighing system or to convert
mechanical scales to electronic. The robust and economical stain-
less steel design is suitable for use in industrial environments.
Model
SLS410, SLS510
Max. Capacity (kg)
50, 100, 250, 500, 1,000, 2,500, 5,000,
7,500, 10,000
Resolution
3,000e
OIML approval
C3 OIML
NTEP approval
III 5,000d
ATEX approval
Zone 1/2 and 21/22
FM approval
Class I, II, III, Div 1&2
Material
Nickel plated steel, stainless steel
Protection
IP67
Interface
Analog 3 mV/V
Application
Suspended hoppers, tension loads
Accessories
Rod ends
Load Cell Accessories
These help to integrate the weighing technology perfectly into a cus-
tomized system.
Accessory
Application
EK – Expansion Kit Optimized for best accuracy and coping with
thermal expansion
EVK / EVKT – Expan- Optimized for accuracy and coping with
sion and Vibration Kit thermal expansion and vibration / shock
FTK / FTKT – Foot Kit Link between floor and load cell with deck
bending
BPK – Base Plate Kit Mount load cell on concrete or other rough
and low strength surfaces
Rod End and Nut
Rod ends for S-type load cell providing flexible
load introduction
www.mt.com/load-cells
